COBE-ETP03MDS Metal material sorter

COBE-ETP03MDS Metal material sorter

COBE-ETP03MDS Metal material sorter with a 50Hz to 10MHz frequency range, able to cope with all sorts of metal piping sorting  ,many different kinds of alarm model, fast digital / automatic electronic balance. Therefore, it can establish standards for the detection and the users can change the specifications of different materials.



Main Technical Data:

◇ Inspection passages: 1 ~8

◇ Frequency range: 50 Hz ~ 10 MHz

◇ Gain range: 0 ~ 99dB continuously adjustable, the work of each file 0.5dB step

◇ Phase Rotation: 0 ~ 359 ° continuously adjustable, precision 1 °.

◇ Detection speed :1-3S/Pc

◇ Adjustable probe stimulus, 1-8

◇ Fast digital / analog electronic balance

◇ Has a unique non-constant-amplitude phase / amplitude domain Alarm

◇ Many display method: impedance,  time base ;

◇ Digital Filter: Low-pass: 0hz ~ 2000hz, high-pass: 0hz ~ 2000h;

◇ Real-time alarm output, alarm output delay

◇ Acousto-optic alarm output

◇ With excision termination/ tail-end signal function

◇ Mass storage can store a variety of testing procedures and test data

◇ Automatically record and display the defects and their position

◇Automatically generate inspection reports(including the number of inspection, acceptance number and rejection number)

◇ Operating Language: Chinese, English
